The Myers MSS-PIR1-WF is a smart sensor from the Myers brand, identified by SKU 7933. This Wi-Fi enabled device connects via IEEE 802.11b/g/n on the 2.4 GHz frequency band and is managed through the Partizan mobile app.
The sensor offers a detection distance of 6 and provides a 360-degree detection angle when ceiling mounted. The device supports both ceiling and wall installation methods, giving flexibility in deployment options. The unit features a plastic housing with compact circular dimensions of 60 mm diameter and 34 mm height, weighing 56 grams.
The MSS-PIR1-WF operates on two LR03 (AAA) batteries with a low battery voltage threshold of 2.4. The sensor functions within an operating temperature range of 0 to 40 °C and humidity levels of 20-95% RH (non-condensing), with storage temperature rated from -20 to 35 °C. The product includes a 3-year warranty.
Product details
| Model |
MSS-PIR1-WF
|
| SKU |
7933
|
Network
| Wi-Fi |
IEEE 802.11b/g/n (2.4 GHz)
|
Electrical specifications
| Idle current |
≤ 65 μA
|
| Peak current |
≤ 135 mA
|
| Low battery voltage |
≤ 2.4 V
|
Mechanical specifications
